Name: Capsule Slip Ring Rotary Joint 36 Circles 2A IP64,300RPM Wind Power Slip Ring LPC-36T
Brand: Capsule Slip Ring Rotary Joint 36 Circles 2A IP64,300RPM Wind Power Slip Ring LPC-36T
SKU: LPC-36T
Rating: 4.9 (132 reviews)

Χαρακτηριστικά Εκθεσιακός χώρος Περιγραφή προϊόντων Ζητήστε ένα απόσπασμα

Χαρακτηριστικά

Προδιαγραφές

Model Number: LPC-36T

Type: Electronic Accessories

Operating Speed: 0-200 rpm

Number of Circuits: 36

Voltage: 240 VAC/DC

Current Rating: 2 amps per circuit

Βασικές πληροφορίες

Model Number: LPC-36T

Πληρωμής & Αποστολής Όροι

Περιγραφή προϊόντων

Product Description

Bargain Price Only in Alibaba

Standard middle-sized Capsule Slip Ring is able to integrate over 125 circuits, with optional outer diameter from 22mm~54mm. This series adopts advanced military-standard surface processing techniques, and is highly precise, compact and easy to assemble. Gold-to-gold contact ensures low resistance and super long service life. It is able to integrate various signals: Ethernet, USB, RS, LVDS, CAN bus, Fire Wire, SDI and HDMI, etc.

Specifications
Operating Speed	0-200 rpm
Number of Circuits	36
Voltage	240 VAC/DC
Current Rating	2 amps per circuit
Temperature Range	-20℃ to +60℃
Contact Material	Gold to Gold
Lead Size	28# silver plated copper
Lead Lengths	Standard 250 mm (9.843inch)
Hole Diameter	1.5~6mm
Dielectric Strength	≥200 VAC @50Hz, between each circuit
Insulation Resistance	50 MΩ @ 500 VDC
Electronic Noise	30mΩ Min

Features:

Military standard surface processing
Precise
Gold-to-gold contact
Low resistance
Long service life

Options:

Rotating speed
Life span
Protection grade
Number of circuits
Current capacity
Size
Housing material
Mass produc-tion

Main applications:

High speed dome
Camera platform
Electrical testing equipment
Rotary table
Manufacturing and control equipment
